Supported processor sockets | LGA 1700 |
Processor manufacturer | Intel |
Processor Socket | LGA 1700 |
Compatible processor series | Intel® Core™ i9 |
Parallel processing technology support | Not supported |
DirectX version | 12.0 |
Motherboard chipset family | Intel |
Motherboard form factor | micro ATX |
audio chip | Realtek ALC897 |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 11 |
MOTHERBOARD CHIPSET | Intel H610 |
Memory slots type | DIMM |
Supported memory clock speeds | 3200 |
ECC сompatibility | Non-ECC |
Supported memory types | DDR4-SDRAM |
Number of memory slots | 2 |
Maximum internal memory | 64 GB |
Memory channels | Dual-channel |
Width | 211 mm |
Height | 65 mm |
Depth | 244 mm |
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet interface type | Gigabit Ethernet |
12V power connector | Yes |
ATX Power connector (24-pin) | Yes |
CPU fan connector | Yes |
TPM connector | Yes |
Number of SATA III connectors | 4 |
Front panel audio connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
USB 2.0 connectors | 2 |
BIOS Type | UEFI AMI |
Drivers included | Yes |
CABLES INCLUDED | SATA |
Supported storage drive interfaces | M.2, SATA III |
Supported storage drive types | SSD |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
DisplayPorts quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
VGA (D-Sub) ports quantity | 1 |
USB 2.0 ports quantity | 4 |
Weight | 764 g |
Harmonized System (HS) code | 84733020 |
Warnings | Before starting any maintenance or installation, disconnect the product from the power supply. |
