Compatible processor series | Intel® Pentium® |
Processor Socket | LGA 1700 |
Processor manufacturer | Intel |
Supported processor sockets | LGA 1700 |
Motherboard form factor | ATX |
MOTHERBOARD CHIPSET | Intel Z790 |
Audio output channels | 7.1 channels |
Motherboard chipset family | Intel |
Windows operating systems supported | Windows 11 x64 |
Number of memory slots | 4 |
Unbuffered memory | Yes |
Supported memory types | DDR5-SDRAM |
Supported memory clock speeds | 4800 |
Maximum internal memory | 128 GB |
Memory channels | Dual-channel |
Supported memory clock speed (max) | 7200 MHz |
Depth | 243.8 mm |
Width | 304.8 mm |
Wi-Fi standards | 802.11a |
Ethernet interface type | 2.5 Gigabit Ethernet |
Wi-Fi | Yes |
Ethernet LAN | Yes |
Bluetooth | Yes |
Bluetooth Version | 5.3 |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
USB 2.0 connectors | 4 |
Number of SATA III connectors | 6 |
RGB LED pin header | Yes |
TPM connector | Yes |
CPU fan connector | Yes |
Chassis intrusion connector | Yes |
Front panel connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
Front panel audio connector | Yes |
Desktop Management Interface (DMI) version | 6.4 |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Supported storage drive interfaces | M.2, PCI Express |
Number of storage drives supported | 10 |
RAID levels | 0 |
Supported storage drive types | HDD & SSD |
DisplayPorts quantity | 1 |
S/PDIF out port | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
Number of M.2 (M) slots | 4 |
