Maximum internal memory supported by processor | 256 GB |
Processor Socket | LGA 1851 (Socket V1) |
Compatible processor series | Intel Core Ultra (Series 2) |
Processor manufacturer | Intel |
Supported processor sockets | Intel LGA1851 |
On-board graphics card | No |
Motherboard form factor | ATX |
Motherboard chipset family | Intel |
Windows operating systems supported | Windows 11 |
MOTHERBOARD CHIPSET | Intel Z890 |
Audio output channels | 7.1 channels |
audio chip | Realtek ALC897 |
Product colour | Black |
ECC сompatibility | Non-ECC |
Number of memory slots | 4 |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Supported memory clock speed (max) | 9200 MHz |
Memory channels | Dual-channel |
Supported memory clock speeds | 9200 MHz |
Maximum internal memory | 256 GB |
Depth | 304.8 mm |
Width | 243.8 mm |
WLAN controller model | Killer Wi-Fi 7 BE1750 |
Wi-Fi standards | 802.11a |
Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
Bluetooth Version | 5.4 |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Ethernet interface type | 5 Gigabit Ethernet |
Bluetooth | Yes |
Number of EPS power connectors (8-pin) | 1 |
USB 2.0 connectors | 4 |
Total number of SATA connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 4 |
Number of SATA III connectors | 4 |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
EPS power connector (8-pin) | Yes |
Number of HDDs supported | 8 |
Supported storage drive interfaces | M.2, SATA III |
Raid Support | Yes |
RAID levels | 5 |
Number of storage drives supported | 4 |
Supported storage drive types | HDD & SSD |
Thunderbolt ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
DisplayPorts quantity | 1 |
DisplayPort version | 1.4 |
HDMI version | 2.1 |
USB 2.0 ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Number of M.2 (M) slots | 4 |
PCI Express x16 (Gen 5.x) slots | 1 |
PCI Express x1 (Gen 4.x) slots | 1 |
PCI Express x4 (Gen 4.x) slots | 2 |
