Supported processor sockets | LGA 1700 |
Compatible processor series | Intel® Core™ i5 |
Processor manufacturer | Intel |
Processor Socket | LGA 1700 |
HDCP | Yes |
Parallel processing technology support | Not supported |
Windows operating systems supported | Windows 11 x64 |
Motherboard form factor | ATX |
audio chip | Realtek ALC1220 |
Audio output channels | 8 channels |
Motherboard chipset family | Intel |
MOTHERBOARD CHIPSET | Intel Z790 |
Component for | PC |
Unbuffered memory | Yes |
Number of memory slots | 4 |
Maximum internal memory | 128 GB |
Supported memory types | DDR5-SDRAM |
Memory slots type | DIMM |
Memory channels | Dual-channel |
ECC сompatibility | Non-ECC |
Supported memory clock speeds | 5600 |
Wi-Fi standards | 802.11a |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Ethernet interface type | 2.5 Gigabit Ethernet |
Bluetooth Version | 5.2 |
LAN controller | Dragon RTL8125BG |
Bluetooth | Yes |
Front panel audio connector | Yes |
Number of SATA III connectors | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
12V power connector | Yes |
USB 2.0 connectors | 2 |
RGB LED pin header | Yes |
ATX Power connector (24-pin) | Yes |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Clear CMOS button | Yes |
CABLES INCLUDED | SATA |
RAID levels | 10 |
Number of storage drives supported | 7 |
Supported storage drive types | HDD & SSD |
Raid Support | Yes |
Supported storage drive interfaces | M.2, PCI Express 4.0, SATA III |
HDMI version | 2.1 |
Ethernet LAN (RJ-45) ports | 1 |
USB connector type | USB Type-C |
Digital audio optical out | 1 |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
HDMI ports quantity | 1 |
Microphone in | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
WiFi-AP antenna jack | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
S/PDIF out port | Yes |
Headphone outputs | 5 |
USB 2.0 ports quantity | 2 |
PCI Express x1 (Gen 3.x) slots | 2 |
PCI Express x16 (Gen 4.x) slots | 2 |
Number of M.2 (M) slots | 1 |
PCI Express x16 (Gen 5.x) slots | 1 |
