O11 DYNAMIC EVO RGB | PC | Tower | Black | Material Tempered glass/Aluminium/Steel | Supported mainboards ATX/Mini-ITX/EATX | 7xNumber of expansion slots | Side window Yes | Illumination Yes | Anti-dust filter Yes | Supported HDD sizes 3.5 "
Description | Introducing the all-new O11D EVO RGB, featuring dual ARGB light strips running through the top and bottom of the chassis,creating a stunning look. And the expanded internal space provides greater component compatibility, bringing an exceptional PC-building experience.
TWO COLORS/TWO MODES Derived from the O11D EVO, the O11D EVO RGB can be displayed in two modes with just a few simple steps, allowing for a left or right view. It also comes in two color options: Black and White.
ARGB STRIPS ON THE TOP AND BOTTOM The O11D EVO RGB features a 1.5mm thick L-shaped ARGB strip at both the top and bottom of the chassis that can switch between 14 different lighting effects, adjust brightness and color, and sync with the Motherboard.
COMPLETELY UNOBSTRUCTED VIEW The O11D EVO RGB’s front pillar can now be easily removed, providing a seamless view for showcasing hardware without affecting the case’s structure.
LARGER SIZE, HIGHER COMPATIBILITY Compared to the O11D EVO, the O11D EVO RGB is slightly larger, which provides higher component compatibility: it supports a 420mm radiator at the top (requires a separate bracket, 360mm radiator at the side/bottom, and 3x140mm fans at all three sides.
MODULAR DESIGN FLEXIBLE CONFIGURATION Modularity has always been one of the design languages of the O11D EVO series, and the O11D EVO RGB is no exception.
ADJUSTABLE Motherboard INSTALLATION The O11D EVO RGB features two sets of pilot holes at different heights, allowing the users to adjust the installation position of the Motherboard to accommodate different builds.
CUSTOMIZED CABLE MANAGEMENT O11D EVO RGB features an improved cable management design, featuring large VELCRO straps near the PSU chamber, dual-layer cable clips that can hold both the bulky and thinner cables, and 15mm of extended space from the rear of the PSU chamber for more cable management room.
ELEVATE YOUR GPU O11D EVO RGB comes with the new anti-sag bracket GB-003 with easy height adjustment to support heavy GPUs.
FRIENDLY STORAGE CAPACITY O11D EVO RGB offers multiple easily accessible storage mounting locations that support up to 8 × SSDs or 4 × HDDs + 2 × SSDs.
OPTIONAL ACCESSORIES Included 2 silicone covers for low mode configuration to provide a clean look for cable management.Two L-shaped light strips on top and bottom with befitting lighting effectsFront and side tempered glass panels with a removable pilar for a seamless view of components and RGB lighting2 heights adujustable Motherboard rear I/O and mounting pointsSupports up to 420mm radiator on top, and 360mm radiator on side and bottomSupports 140mm fans x3 on top, side, and bottomCable management friendly with more space at the second chamberOptional accesories for vertical GPU or upright GPU mounting |
Summary | Lian Li 011 Dynamic EVO RGB O11D EVO RGB. Form factor: Tower, Type: PC, Product colour: Black. Side fans diameters supported: 120,140 mm, Rear fans diameters supported: 120 mm, Top fans diameters supported: 120,140 mm. Supported HDD sizes: 3.5", SSD form factor: 2.5". Width: 290 mm, Depth: 478 mm, Height: 471 mm |
Vendor Homepage | https://lian-li.com/product/o11d-evo-rgb/ |
Category Code | CAS |
Unit Box Height | 0.55 |
Unit Box Length | 0.61 |
Unit Box Width | 0.39 |
Anti-dust filter | Yes |
Form factor | Tower |
Illumination | Yes |
Illumination colour | Multi |
Material | Aluminium/Steel/Tempered glass |
Maximum CPU cooler height | 167 mm |
Maximum graphics card length | 455.7 mm |
Number of Expansion Slots | 7 |
On/off button | Yes |
Product colour | Black |
Reset button | Yes |
Side window | Yes |
Supported motherboard form factors | ATX/EATX/Mini-ITX |
Tempered glass panel(s) | Yes |
Type | PC |
Audio Input | Yes |
USB 2.0 ports quantity | 2 |
USB 3.0 | 2 |
USB Type-C ports quantity | 1 |
Bottom fans diameters supported | 120/140 mm |
Bottom radiator sizes supported | 240/280/360 mm |
Number of bottom fans supported (max) | 3 |
Number of rear fans supported (max) | 1 |
Number of side fans supported (max) | 3 |
Number of top fans supported (max) | 3 |
Rear fans diameters supported | 120 mm |
Side fans diameters supported | 120/140 mm |
Side radiator sizes supported | 240/280/360 mm |
Top fans diameters supported | 120/140 mm |
Top radiator sizes supported | 240/360/420 mm |
HDD/SSD combo cage | Yes |
SSD form factor | 2.5" |
Supported HDD sizes | 3.5 " |
Warranty period | 1 year(s) |
Depth | 478 mm |
Height | 471 mm |
Width | 290 mm |
Model name | O11 DYNAMIC EVO RGB |
Model | O11DERGBX |
Units per Shipping Box | 1 |
Unit Calculated Volume | 0.1308 cubm |
Unit Calculated Weight | 17.4 kg |
