Launch date | Q1'24 |
Status | Launched |
OpenCL version | 3.0 |
Processor codename | Raptor Lake |
Processor threads | 8 |
Processor cache type | Smart Cache |
Memory bandwidth supported by processor (max) | 76.8 GB/s |
Bus type | DMI4 |
Processor cores | 4 |
Processor manufacturer | Intel |
Performance-core base frequency | 3.5 GHz |
Processor model | i3-14100 |
Box | Yes |
Cooler included | Yes |
Processor Socket | LGA 1700 |
Performance cores | 4 |
Maximum number of DMI lanes | 8 |
Maximum turbo power | 110 W |
Processor cache | 12 MB |
Processor family | Intel® Core™ i3 |
Processor base power | 60 W |
Performance-core boost frequency | 4,7 GHz |
Processor generation | Intel Core i3-14xxx |
Processor boost frequency | 4.7 GHz |
Processor operating modes | 64-bit |
On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
On-board graphics card model | Intel UHD Graphics 730 |
On-board graphics card outputs supported | HDMI 2.1 |
Discrete graphics card | No |
On-board graphics card OpenGL version | 4.5 |
On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
On-board graphics card ID | 0x4692 |
On-board graphics card | Yes |
Discrete graphics card model | Not available |
Number of displays supported (on-board graphics) | 4 |
On-board graphics card base frequency | 300 MHz |
On-board graphics card dynamic frequency (max) | 1500 MHz |
Multi-Format Codec Engines | 1 |
On-board graphics card DirectX version | 12.0 |
Number of execution units | 24 |
Supported instruction sets | SSE4.2 |
Scalability | 1S |
Maximum number of PCI Express lanes | 20 |
CPU configuration (max) | 1 |
Idle States | Yes |
Market segment | Desktop |
Embedded options available | Yes |
Execute Disable Bit | Yes |
Use conditions | PC/Client/Tablet |
Direct Media Interface (DMI) Revision | 4.0 |
Thermal Monitoring Technologies | Yes |
PCI Express configurations | 1x16+1x4 |
PCI Express slots version | 4.0 |
Memory channels | Dual-channel |
Memory bandwidth (max) | 76.8 GB/s |
Maximum internal memory supported by processor | 192 GB |
Memory types supported by processor | DDR4-SDRAM |
Non-ETC | Yes |
Tjunction | 100 °C |
Processor package size | 45 x 37.5 mm |
Intel® Boot Guard | Yes |
Intel® OS Guard | Yes |
Intel® Volume Management Device (VMD) | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel Turbo Boost Max Technology 3.0 | No |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Mode-based Execute Control (MBE) | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Secure Key | Yes |
Intel 64 | Yes |
Intel® Thread Director | No |
Intel® Standard Manageability (ISM) | Yes |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
Intel® Quick Sync Video Technology | Yes |
Intel® Control-flow Enforcement Technology (CET) | Yes |
Intel® Threat Detection Technology (TDT) | Yes |
Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
L2 CACHE | 5120 KB |
Maximum internal memory | 192 GB |
