Target market | Gaming |
OpenCL version | 2.1 |
Launch date | Q1'22 |
Status | Launched |
Processor cores | 6 |
Processor operating modes | 64-bit |
Processor model | i5-12400 |
Processor family | Intel® Core™ i5 |
Processor cache type | Smart Cache |
Processor codename | Alder Lake |
Processor manufacturer | Intel |
Processor Socket | LGA 1700 |
Processor threads | 12 |
Processor boost frequency | 4.4 GHz |
Processor cache | 18 MB |
Performance-core base frequency | 2.5 GHz |
Performance-core boost frequency | 4.4 GHz |
Processor base power | 65 W |
Bus type | DMI4 |
Memory bandwidth supported by processor (max) | 76.8 GB/s |
Box | Yes |
Processor generation | 12th gen Intel® Core™ i5 |
Cooler included | Yes |
Maximum number of DMI lanes | 8 |
Maximum turbo power | 117 W |
Performance cores | 6 |
Discrete graphics card model | Not available |
Number of execution units | 24 |
On-board graphics card DirectX version | 12.0 |
On-board graphics card | Yes |
On-board graphics card model | Intel UHD Graphics 730 |
Discrete graphics card | No |
On-board graphics card base frequency | 300 MHz |
On-board graphics card dynamic frequency (max) | 1450 MHz |
Number of displays supported (on-board graphics) | 4 |
On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b |
On-board graphics card ID | 0x4692 / 0x4682 |
On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
On-board graphics card OpenGL version | 4.5 |
Multi-Format Codec Engines | 1 |
Execute Disable Bit | Yes |
Maximum number of PCI Express lanes | 20 |
Thermal Monitoring Technologies | Yes |
CPU configuration (max) | 1 |
PCI Express configurations | 1x16+1x4 |
PCI Express slots version | 5.0 |
Embedded options available | No |
Idle States | Yes |
Scalability | 1S |
Supported instruction sets | SSE4.2 |
Harmonized System (HS) code | 8542310001 |
Use conditions | PC/Client/Tablet |
Direct Media Interface (DMI) Revision | 4.0 |
Export Control Classification Number (ECCN) | 5A992CN3 |
Market segment | Desktop |
Commodity Classification Automated Tracking System (CCATS) | G167599 |
Memory channels | Dual-channel |
Memory bandwidth (max) | 76.8 GB/s |
Maximum internal memory supported by processor | 128 GB |
Memory types supported by processor | DDR5-SDRAM |
Tjunction | 100 °C |
Processor package size | 45 x 37.5 mm |
Intel® Secure Key | Yes |
Intel 64 | Yes |
Intel® Optane™ Memory Ready | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel® OS Guard | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Quick Sync Video Technology | Yes |
Intel Turbo Boost Max Technology 3.0 | No |
Intel® Thread Director | No |
Intel® Volume Management Device (VMD) | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
Intel® Control-flow Enforcement Technology (CET) | Yes |
Intel® Boot Guard | Yes |
Intel® Speed Shift Technology | Yes |
Maximum internal memory | 128 GB |
Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
