Launch date | Q1'23 |
Processor cores | 10 |
Processor model | i5-13400F |
Processor ARK ID | 230501 |
Processor operating modes | 64-bit |
Processor threads | 16 |
Processor Socket | LGA 1700 |
Processor boost frequency | 4.6 GHz |
Box | Yes |
Processor family | Intel® Core™ i5 |
Processor cache | 20 MB |
Processor cache type | Smart Cache |
Processor manufacturer | Intel |
Processor codename | Raptor Lake |
Cooler included | Yes |
Efficient-core base frequency | 1.8 GHz |
Efficient cores | 4 |
Maximum turbo power | 148 W |
Performance-core boost frequency | 4.6 GHz |
Processor generation | 13th gen Intel® Core™ i5 |
Maximum number of DMI lanes | 8 |
Efficient-core boost frequency | 3.3 GHz |
Performance cores | 6 |
Processor base power | 65 W |
Performance-core base frequency | 2.5 GHz |
Discrete graphics card | No |
On-board graphics card model | Not available |
Discrete graphics card model | Not available |
On-board graphics card | No |
Market segment | Desktop |
Execute Disable Bit | Yes |
Supported instruction sets | SSE4.1 |
PCI Express configurations | 1x16+1x4 |
Scalability | 1S |
CPU configuration (max) | 1 |
PCI Express slots version | 4.0 |
Maximum number of PCI Express lanes | 20 |
Embedded options available | No |
Idle States | Yes |
Thermal Monitoring Technologies | Yes |
Direct Media Interface (DMI) Revision | 4.0 |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Export Control Classification Number (ECCN) | 5A992C |
Use conditions | PC/Client/Tablet |
Memory channels | Dual-channel |
Memory bandwidth (max) | 76.8 GB/s |
Memory types supported by processor | DDR5-SDRAM |
Maximum internal memory supported by processor | 192 GB |
Non-ETC | Yes |
Tjunction | 100 °C |
Processor package size | 45 x 37.5 mm |
Intel® Secure Key | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel 64 | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel® OS Guard | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Intel Turbo Boost Max Technology 3.0 | No |
Mode-based Execute Control (MBE) | Yes |
Intel® Volume Management Device (VMD) | Yes |
Intel® Boot Guard | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
Intel® Thread Director | Yes |
Intel® Standard Manageability (ISM) | Yes |
Intel® Control-flow Enforcement Technology (CET) | Yes |
Maximum internal memory | 192 GB |
L2 CACHE | 9728 KB |
Harmonized System (HS) code | 8542310001 |
