OpenCL version | 3.0 |
Status | Launched |
Launch date | Q1'24 |
Processor codename | Raptor Lake |
Stepping | B0 |
Processor family | Intel® Core™ i9 |
Processor cache | 36 MB |
Processor boost frequency | 5.8 GHz |
Processor manufacturer | Intel |
Processor operating modes | 64-bit |
Processor model | i9-14900 |
Memory bandwidth supported by processor (max) | 89.6 GB/s |
Processor threads | 32 |
Processor cores | 24 |
Processor cache type | Smart Cache |
Processor Socket | LGA 1700 |
Processor ARK ID | 236793 |
Efficient cores | 16 |
Box | Yes |
Performance-core base frequency | 2 GHz |
Processor generation | Intel® Core™ i9 (14th gen) |
Maximum number of DMI lanes | 8 |
Cooler included | Yes |
Performance cores | 8 |
Processor base power | 65 W |
Performance-core boost frequency | 5.4 GHz |
Maximum turbo power | 219 W |
Efficient-core boost frequency | 4.3 GHz |
Efficient-core base frequency | 1.5 GHz |
On-board graphics card DirectX version | 12.0 |
On-board graphics card | Yes |
Number of execution units | 32 |
On-board graphics card model | Intel UHD Graphics 770 |
Discrete graphics card | No |
Discrete graphics card model | Not available |
On-board graphics card base frequency | 300 MHz |
On-board graphics card ID | 0xA780 |
On-board graphics card outputs supported | HDMI 2.1 |
On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
Multi-Format Codec Engines | 2 |
On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
On-board graphics card dynamic frequency (max) | 1650 MHz |
Number of displays supported (on-board graphics) | 4 |
On-board graphics card OpenGL version | 4.5 |
Supported instruction sets | SSE4.1 |
Scalability | 1S |
Embedded options available | Yes |
Idle States | Yes |
PCI Express configurations | 1x16+1x4 |
Thermal Monitoring Technologies | Yes |
Execute Disable Bit | Yes |
CPU configuration (max) | 1 |
Maximum number of PCI Express lanes | 20 |
PCI Express slots version | 4.0 |
Export Control Classification Number (ECCN) | 5A992C |
Use conditions | PC/Client/Tablet |
Direct Media Interface (DMI) Revision | 4.0 |
Market segment | Desktop |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Maximum internal memory supported by processor | 192 GB |
Memory types supported by processor | DDR4-SDRAM |
Memory channels | Dual-channel |
ETC | Yes |
Memory bandwidth (max) | 89.6 GB/s |
Tjunction | 100 °C |
Processor package size | 45 x 37.5 mm |
Intel® Secure Key | Yes |
Intel® Quick Sync Video Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel 64 | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® OS Guard | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
Intel® Control-flow Enforcement Technology (CET) | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Boot Guard | Yes |
Intel Turbo Boost Max Technology 3.0 | Yes |
Intel® Standard Manageability (ISM) | Yes |
Intel® Volume Management Device (VMD) | Yes |
Intel® Turbo Boost Max Technology 3.0 frequency | 5.6 GHz |
Intel® Thermal Velocity Boost | Yes |
Intel® Thread Director | Yes |
Intel® Adaptive Boost Technology | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel® Thermal Velocity Boost Frequency | 5.8 GHz |
Maximum internal memory | 192 GB |
Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
L2 CACHE | 32768 KB |
Harmonized System (HS) code | 8542310001 |
