processor | 265K |
processor manufacturer | Intel |
processor generation | Intel Core Ultra (Series 2) |
processor family | Intel Core Ultra 7 |
number of CPU cores | 20 |
processor socket | FCLGA1851 |
processor threads | 20 |
Processor Operating Modes | 64-Bit |
performance cores | 8 |
Efficient Cores | 12 |
Processor Boost Frequency | 5,5 GHz |
Power core boost frequency | 5,4 GHz |
Power Fundamental frequency of the core | 3,9 GHz |
Efficient core boost frequency | 4,6 GHz |
Efficient base frequency of the core | 3,3 GHz |
processor cache | 30 MB |
processor cache type | Smart Cache |
Eigenschaft | Intel® Total Memory Encryption - Multi Key |
Base performance of the processor | 125 W |
Maximum turbo performance | 250 W |
Von der CPU unterstützte AI-Software-Frameworks | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
Stepping | B0 |
Maximum number of DMI tracks | 8 |
Processor code name | Arrow Lake |
ARK processor detection | 241063 |
Neuronale Prozessoreinheit (NPU) | Intel AI Boost |
Von der NPU unterstützte AI-Software-Frameworks | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
Gesamtleistung des Prozessors bis zu | 33 TOPs |
NPU-Leistung bis zu | 13 TOPs |
GPU-Leistung bis zu | 8 TOPs |
Storage | |
Maximum internal memory supported by the processor | 192 GB |
Memory types supported by the processor | DDR5-SDRAM |
Memory clock speeds supported by the processor | 6400 MHz |
memory channels | Zweikanalig |
graphic | |
Eingebautes Grafikkartenmodell | Intel Graphics |
On-board graphics adapter supported outputs | HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1 |
On-board graphics adapter base frequency | 300 MHz |
Maximum dynamic frequency of the on-board graphics adapters | 2000 MHz |
Number of supported displays (on-board graphics) | 4 |
On-Board Grafikadapter DirectX Version | 12.0 |
On-Board Grafikadapter OpenGL Version | 4.5 |
On-board graphics adapter Device ID | 0x7D67 |
Separates Grafikkartenmodell | Nicht verfügbar |
Xe-Kerne | 4 |
features | |
market segment | Desktop |
Terms of Use | Arbeitsstation, PC/Client/Tablet |
Maximum number of PCI Express lanes | 24 |
PCI-Express-Slots-Version | 4.0, 5.0 |
Supported Instruction Sets | AVX 2.0, SSE4.1, SSE4.2 |
scalability | 1S |
Specification of the thermal solution | PCG 2020A |
Direct Media Interface (DMI) revision | 4.0 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification System for Automated Tracking (CCATS) | 740.17B1 |
Processor specifics | |
Intel® Turbo-Boost Technology | 2.0 |
Intel® Turbo Boost Max Technology 3.0 frequency | 5,5 GHz |
operating conditions | |
Maximum operating temperature | 105 °C |
Technical details | |
OpenCL-Version | 3.0 |
Start date | Q4'24 |
Status | Launched |
Speichergeschwindigkeit (max.) | 6400 MHz |
logistic data | |
Goods tariff number (HS) | 8542310050 |
Other functions | |
Buffer memory L2 | 36864 KB |
RAM memory maximum | 192 GB |
Graphic output | DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b |
