energy | |
overall performance | 1000 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Maximum input current (at 110V) | 15 A |
Maximum input current (at 220V) | 8 A |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 100 W |
Combined power (+12V) | 999,6 W |
Combined current (+5V) | 100 W |
Combined current (-12V) | 4,8 W |
Combined current (+5Vsb) | 15 W |
Max. output current (+3.3V) | 20 A |
Max. output current (+12V) | 83,3 A |
Max output current (+5V) | 20 A |
Max. output current (-12V) | 0,4 A |
Max. output current (+5Vsb) | 3 A |
efficiency | 90% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Power cable length motherboard | 65 cm |
Number of SATA power plugs | 10 |
Number of PATA power connections | 5 |
SATA power cable length | 500,650,800,950 mm |
Number of Molex connectors 4pin | 5 |
Peripheral (Molex) power cord length | 350,500,650,800 mm |
Number of PCI Express power connectors 6+2pin | 6 |
PCI Express-Stromanschlüsse (12+4 Pol) | 1 |
PCI Express-Stromanschlüsse (12+4-polig) Kabellänge | 600 mm |
PCI Express power cord length | 75 cm |
Eigenschaft | CPU Stecker (4+4 pin) |
CPU performance cable length | 65 cm |
cable type | Vollständig modular |
Services | |
80 plus certification | 80 PLUS Gold |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 3.1 |
Design | |
Product color | Weiß |
fan diameter | 13,5 cm |
number of fans | 1 Lüfter |
weight and dimensions | |
broad | 150 mm |
depth | 151 mm |
height | 86 mm |
Weight | 2,63 kg |
