energy | |
overall performance | 1000 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 120 W |
Combined power (+12V) | 1000 W |
Combined current (+5V) | 120 W |
Combined current (-12V) | 3,6 W |
Combined current (+5Vsb) | 15 W |
Max. output current (+3.3V) | 22 A |
Max. output current (+12V) | 83,5 A |
Max output current (+5V) | 22 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 3 A |
efficiency | 90% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Überhitzung, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Power cable length motherboard | 60 cm |
Number of SATA power plugs | 12 |
SATA power cable length | 500,650,700,850 mm |
Number of Molex connectors 4pin | 4 |
Peripheral (Molex) power cord length | 1100,500,650,700,850 mm |
Eigenschaft | Diskettenlaufwerkstecker |
Number of PCI Express power connectors 6+2pin | 6 |
PCI Express power connectors (16-pin) | 1 |
PCI Express power cord length | 75 cm |
cable type | Vollständig modular |
Services | |
80 plus certification | 80 PLUS Gold |
purpose | PC / Server |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 3.0 |
storage type | FDB |
Design | |
Product color | Schwarz |
cooling | Aktiv |
fan diameter | 13,5 cm |
number of fans | 1 Lüfter |
weight and dimensions | |
broad | 150 mm |
depth | 150 mm |
height | 86 mm |
Other functions | |
EPS cable length | 70 cm |
