energy | |
overall performance | 1200 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 15 - 7.5 A |
Combined Current (+3.3V) | 125 W |
Combined power (+12V) | 1200 W |
Combined current (+5V) | 125 W |
Combined current (-12V) | 3,6 W |
Combined current (+5Vsb) | 15 W |
Max. output current (+3.3V) | 25 A |
Max. output current (+12V) | 100 A |
Max output current (+5V) | 25 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 3 A |
energy conservation properties | Überlastung, Überspannung, Kurzschluß, Unter Strom |
connections and interfaces | |
Motherboard connector plug | 24-pin ATX |
Power cable length motherboard | 61 cm |
SATA power cable length | 470,550,570,700,760,860,950 mm |
Number of Molex connectors 4pin | 3 |
Peripheral (Molex) power cord length | 470,690 mm |
Eigenschaft | ATX Stromstecker (20+4 pol.) |
PCI Express power connectors (16-pin) | 1 |
PCI Express power cord length | 75 cm |
CPU performance cable length | 65 cm |
cable type | Vollständig modular |
Services | |
80 plus certification | 80 PLUS Platinum |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 3.0 |
storage type | FDB |
Mean Time Between Failures (MTBF) | 150000 h |
Design | |
Product color | Schwarz |
cooling | Aktiv |
fan diameter | 13,5 cm |
number of fans | 1 Lüfter |
operating conditions | |
operating temperatur | 0 - 50 °C |
scope of delivery | |
Supplied cables | CPU, PCIe, Peripheral (Molex), SATA |
weight and dimensions | |
broad | 150 mm |
depth | 160 mm |
height | 86 mm |
packaging type | Box |
Technical details | |
sustainability certificates | ENERGY STAR |
Konformitätsbescheinigungen | REACH, RoHS, WEEE |
