energy | |
overall performance | 400 W |
peak current | 450 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 6 A |
power factor | 0,99 |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 120 W |
Combined power (+12V) | 384 W |
Combined current (+5V) | 120 W |
Combined current (-12V) | 3,6 W |
Combined current (+5Vsb) | 15 W |
Max. output current (+3.3V) | 24 A |
Max. output current (+12V1) | 24 A |
Max output current (+12V2) | 20 A |
Max output current (+5V) | 15 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 3 A |
holding time | 29 ms |
efficiency | 92% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Überhitzung, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Power cable length motherboard | 45 cm |
Number of SATA power plugs | 5 |
Number of PATA power connections | 2 |
SATA power cable length | 450,600,750 mm |
Number of PCI Express power connectors 6+2pin | 2 |
PCI Express power cord length | 50 cm |
Eigenschaft | Kabelbinder inklusive |
CPU performance cable length | 6 cm |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Gold |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 2.4 |
storage type | Gewehr |
safety | CE, CB, TÜV, FCC, cTUVus, RCM, BSMI, CU, CCC |
certification | ErP, WEEE |
Design | |
Product color | Schwarz |
fan diameter | 12 cm |
number of fans | 1 Lüfter |
weight and dimensions | |
broad | 150 mm |
depth | 150 mm |
height | 86 mm |
Weight | 1,93 kg |
package weight | 2,22 kg |
packaging type | Box |
Technical details | |
sustainability certificates | ENERGY STAR |
Konformitätsbescheinigungen | RoHS |
logistic data | |
Shipping box width | 326 mm |
Shipping carton length | 514 mm |
Shipping carton height | 241 mm |
Shipping carton weight | 14,5 kg |
Goods tariff number (HS) | 84733020 |
Number of products per shipping carton | 6 Stück(e) |
Other functions | |
Noise Level (Quiet Mode, <30%) | 10,5 dB |
Noise level (sleep mode, 50%) | 11,4 dB |
Noise level (full load mode, 100%) | 14,9 dB |
