energy | |
overall performance | 400 W |
peak current | 450 W |
AC input voltage | 230 V |
AC input frequency | 50 Hz |
input current | 3 A |
Maximum input current (at 110V) | +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V |
Power Factor Correction Filter (PFC) | Aktiv |
Combined current (-12V) | 6 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 24 A |
Max. output current (+12V1) | 17 A |
Max output current (+12V2) | 14 A |
Max output current (+5V) | 15 A |
Max. output current (-12V) | 0,5 A |
Max. output current (+5Vsb) | 2,5 A |
efficiency | 89,14% |
energy conservation properties | Überlastung, Überspannung, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Number of SATA power plugs | 6 |
Number of PATA power connections | 3 |
Number of PCI Express power connector 6pin | 1 |
Number of PCI Express power connectors 6+2pin | 1 |
Eigenschaft | ATX Stromstecker (20+4 pol.) |
Floppy drive power connection | 2 |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Bronze |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 2.31 |
Design | |
Product color | Grau |
fan diameter | 12 cm |
number of fans | 1 Lüfter |
certificates | |
certification | TÜV, CE |
weight and dimensions | |
broad | 150 mm |
depth | 140 mm |
height | 85 mm |
Weight | 1,44 kg |
logistic data | |
Goods tariff number (HS) | 84733020 |
