energy | |
overall performance | 600 W |
AC input voltage | 200 - 240 V |
AC input frequency | 50 Hz |
input current | 4.5 A |
Maximum input current (at 220V) | 4,5 A |
power factor | 0,9 |
Power Factor Correction Filter (PFC) | Aktiv |
Combined current (-12V) | 4,8 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 20 A |
Max. output current (+12V1) | 45 A |
Max output current (+5V) | 20 A |
Max. output current (-12V) | 0,4 A |
Max. output current (+5Vsb) | 2,5 A |
energy conservation properties | Kurzschluß, Überspannung und Zustrom, Überspannungsschutz |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Power cable length motherboard | 65 cm |
Number of SATA power plugs | 4 |
SATA power cable length | 450,600,750 mm |
Peripheral (Molex) power cord length | 450,600,750 mm |
Eigenschaft | Ein-/Ausschalter |
Number of PCI Express power connectors 6+2pin | 2 |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS |
Supported motherboard form factors | ATX |
purpose | PC / Server |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 2.3 |
Design | |
Product color | Schwarz |
fan diameter | 12 cm |
weight and dimensions | |
broad | 150 mm |
depth | 140 mm |
height | 86 mm |
Weight | 1,34 kg |
Technical details | |
warranty period | 2 Jahr(e) |
