energy | |
overall performance | 650 W |
AC input voltage | 220 - 240 V |
AC input frequency | 50/60 Hz |
input current | 5 A |
power factor | 0,9 |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 100 W |
Combined power (+12V) | 649,2 W |
Combined current (+5V) | 100 W |
Combined current (-12V) | 3,6 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 20 A |
Max. output current (+12V) | 54,1 A |
Max output current (+5V) | 20 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 2,5 A |
holding time | 17 ms |
efficiency | 85% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Überhitzung, Kurzschluß |
connections and interfaces | |
Motherboard connector plug | 24-pin ATX |
Number of SATA power plugs | 8 |
Number of Molex connectors 4pin | 2 |
Eigenschaft | Nachhaltigkeitskonformität |
Number of PCI Express power connectors 6+2pin | 4 |
Number of PCI Express power connector 8pin | 1 |
Floppy drive power connection | 1 |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Gold |
purpose | PC / Server |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 2.4 |
EPS-Version | 2.92 |
storage type | Schutzhülle |
certification | IEC 62368 |
Design | |
Product color | Schwarz |
cooling | Aktiv |
fan diameter | 12 cm |
number of fans | 1 Lüfter |
fan placement | Oben |
scope of delivery | |
Supplied cables | CPU, PCIe, Peripheral (Molex), SATA |
weight and dimensions | |
broad | 140 mm |
depth | 150 mm |
height | 86 mm |
Weight | 1,46 kg |
Technical details | |
sustainability certificates | ErP |
