energy | |
overall performance | 650 W |
AC input voltage | 230 V |
AC input frequency | 47 - 63 Hz |
input current | 5 A |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 100 W |
Combined power (+12V) | 600 W |
Combined current (+5V) | 100 W |
Max. output current (+3.3V) | 18 A |
Max. output current (+12V) | 50 A |
Max output current (+5V) | 18 A |
Max. output current (-12V) | 0,5 A |
Max. output current (+5Vsb) | 2,5 A |
efficiency | 88% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Power cable length motherboard | 55 cm |
Number of SATA power plugs | 5 |
Number of PATA power connections | 3 |
SATA power cable length | 550,650,750 mm |
Number of PCI Express power connectors 6+2pin | 2 |
Eigenschaft | PCI Express Stecker |
CPU performance cable length | 45 cm |
Floppy drive power connection | 1 |
Floppy drive cable length | 55 cm |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Bronze |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 2.3 |
Design | |
Product color | Schwarz |
fan diameter | 12 cm |
number of fans | 1 Lüfter |
fan placement | Oben |
certificates | |
Konformitätsbescheinigungen | RoHS |
certification | CE, TÜV |
weight and dimensions | |
broad | 150 mm |
depth | 140 mm |
height | 86 mm |
Weight | 2,08 kg |
packaging type | Box |
logistic data | |
Goods tariff number (HS) | 84733020 |
