energy | |
overall performance | 700 W |
AC input voltage | 100 - 240 V |
AC input frequency | 47 - 63 Hz |
input current | 10 A |
power factor | 0,9 |
Power Factor Correction Filter (PFC) | Aktiv |
Combined power (+12V) | 648 W |
Combined current (-12V) | 3,6 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 19 A |
Max. output current (+12V) | 54 A |
Max output current (+5V) | 17 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 2,5 A |
energy conservation properties | Überspannung, Überhitzung, Überlastschutz, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Power cable length motherboard | 65 cm |
Number of SATA power plugs | 6 |
SATA power cable length | 150,500 mm |
Number of Molex connectors 4pin | 3 |
Peripheral (Molex) power cord length | 150,500 mm |
Eigenschaft | ATX Stromstecker (20+4 pol.) |
Number of PCI Express power connectors 6+2pin | 2 |
PCI Express power cord length | 50 cm |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Bronze |
Supported motherboard form factors | ATX |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
certification | ErP, CE, CB, EAC, TUV |
Design | |
Product color | Schwarz |
fan diameter | 12 cm |
number of fans | 1 Lüfter |
weight and dimensions | |
broad | 150 mm |
depth | 140 mm |
height | 87 mm |
Weight | 1,74 kg |
package weight | 2,15 kg |
packaging type | Box |
Technical details | |
Konformitätsbescheinigungen | RoHS |
logistic data | |
Goods tariff number (HS) | 84733020 |
Other functions | |
EPS cable length | 65 cm |
