energy | |
overall performance | 750 W |
AC input voltage | 200 - 240 V |
AC input frequency | 47 - 63 Hz |
power factor | 0,9 |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 120 W |
Combined power (+12V) | 744 W |
Combined current (+5V) | 120 W |
Combined current (+5Vsb) | 2,5 W |
Max. output current (+3.3V) | 22 A |
Max. output current (+12V1) | 62 A |
Max output current (+5V) | 22 A |
Max. output current (-12V) | 0,3 A |
energy conservation properties | Überstrom, Überspannung, Überhitzung, Überlastschutz, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Number of SATA power plugs | 8 |
Number of Molex connectors 4pin | 3 |
Eigenschaft | EPS Stromstecker (8-pin) |
Number of PCI Express power connectors 6+2pin | 4 |
Floppy drive power connection | 1 |
cable type | Semi-Modular |
Services | |
purpose | PC |
Power supply unit (PSU) form factor | PS/2 |
ATX-Version | 2.3 |
Design | |
Product color | Schwarz |
fan diameter | 14 cm |
number of fans | 1 Lüfter |
fan placement | Oben |
weight and dimensions | |
broad | 160 mm |
depth | 150 mm |
height | 87 mm |
logistic data | |
Goods tariff number (HS) | 84733020 |
Other functions | |
Frequenztoleranz | 90% |
