energy | |
overall performance | 800 W |
AC input voltage | 100 - 240 V |
AC input frequency | 47 - 63 Hz |
input current | 10/5 A |
Combined Current (+3.3V) | 100 W |
Combined power (+12V) | 800 W |
Combined current (+5V) | 100 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 20 A |
Max. output current (+12V) | 66 A |
Max output current (+5V) | 20 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 2,4 A |
efficiency | 93,4% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Kurzschluß |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Number of SATA power plugs | 6 |
Number of Molex connectors 4pin | 3 |
Number of PCI Express power connectors 6+2pin | 4 |
Eigenschaft | PCI Express Stecker |
Floppy drive power connection | 1 |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Gold |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 2.4 |
noise level | 38,4 dB |
Design | |
Product color | Schwarz |
fan diameter | 14 cm |
number of fans | 1 Lüfter |
scope of delivery | |
Supplied cables | AC |
weight and dimensions | |
broad | 150 mm |
depth | 160 mm |
height | 86 mm |
Weight | 1,98 kg |
package weight | 2,33 kg |
logistic data | |
Goods tariff number (HS) | 84733020 |
