energy | |
overall performance | 850 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
input current | 10 A |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 100 W |
Combined power (+12V) | 849,6 W |
Combined current (+5V) | 100 W |
Combined current (-12V) | 4,8 W |
Combined current (+5Vsb) | 15 W |
Max. output current (+3.3V) | 20 A |
Max. output current (+12V) | 70,8 A |
Max output current (+5V) | 20 A |
Max. output current (-12V) | 0,4 A |
Max. output current (+5Vsb) | 3 A |
efficiency | 92% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Überhitzung, Kurzschluß, Unterspannung |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Power cable length motherboard | 65 cm |
Number of SATA power plugs | 10 |
SATA power cable length | 500,650,800,950 mm |
Number of Molex connectors 4pin | 5 |
Peripheral (Molex) power cord length | 350,500,650,800 mm |
Eigenschaft | Ein-/Ausschalter |
Number of PCI Express power connectors 6+2pin | 4 |
PCI Express-Stromanschlüsse (12+4 Pol) | 1 |
PCI Express-Stromanschlüsse (12+4-polig) Kabellänge | 600 mm |
CPU P4 connector (4-pin) | 1 |
CPU performance cable length | 80 cm |
cable type | Vollständig modular |
Services | |
80 plus certification | 80 PLUS Platinum |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX-Version | 3.0 |
Design | |
Product color | Schwarz |
fan diameter | 13,5 cm |
number of fans | 1 Lüfter |
certificates | |
certification | CE, TÜV |
weight and dimensions | |
broad | 180 mm |
depth | 150 mm |
height | 86 mm |
Weight | 2,92 kg |
package weight | 3,25 kg |
packaging type | Box |
