On/off switch | Yes |
Fan Diameter | 12 cm |
Product colour | Black |
Power factor | 0.9 |
Maximum input current (@220V) | 4.5 A |
Combined power (+5Vsb) | 12.5 W |
AC input frequency | 50 Hz |
Max output current (+12V1) | 45 A |
Max output current (+5Vsb) | 2.5 A |
Power protection features | Short circuit |
Max output current (+3.3V) | 20 A |
Combined power (-12V) | 4.8 W |
Total power | 600 W |
AC input voltage | 200 - 240 V |
Power Factor Correction (PFC) type | Active |
Input current | 4.5 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.4 A |
Depth | 140 mm |
Weight | 1.34 kg |
Width | 150 mm |
Height | 86 mm |
Purpose | PC/Server |
Power supply unit (PSU) form factor | ATX |
ATX version | 2.3 |
80 PLUS Certification | 80 PLUS |
Supported motherboard form factors | ATX |
Number of SATA power connectors | 4 |
SATA power cable length | 750 |
Cabling Type | Non-Modular |
CPU power connector (4+4 pin) | Yes |
PCI Express power connectors (6+2 pin) | 2 |
Motherboard power cable length | 65 cm |
Peripheral (Molex) power cable length | 750 mm |
ATX power connector (20+4 pin) | Yes |
Motherboard power connector | 20+4 pin ATX |
EPS power connector (4+4 pin) | Yes |
Warranty period | 2 year(s) |
