Product colour | Silver |
Fan location | Top |
Fan Diameter | 12 cm |
Cooling type | Active |
Number of fans | 1 fan(s) |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
Input current | 5 A |
Efficiency | 80% |
AC input voltage | 200 - 240 V |
Max output current (+3.3V) | 22 A |
Combined power (+5V) | 130 W |
AC input frequency | 47 - 63 Hz |
Power factor | 0.9 |
Max output current (+12V) | 50 A |
Power protection features | Overload |
Combined power (-12V) | 3.6 W |
Max output current (+5V) | 22 A |
Total power | 700 W |
Combined power (+12V) | 648 W |
Combined power (+3.3V) | 130 W |
Power Factor Correction (PFC) type | Active |
Combined power (+5Vsb) | 12.5 W |
Depth | 150 mm |
Weight | 1.44 kg |
Height | 87 mm |
Width | 140 mm |
Power supply unit (PSU) form factor | PS/2 |
ATX version | 2.3 |
Purpose | PC/Server |
Package Type | Box |
PACKAGE WEIGHT | 1.57 kg |
Compliance certificates | CE |
CPU power cable length | 55 cm |
Number of SATA power connectors | 6 |
ATX power connector (20+4 pin) | Yes |
Motherboard power connector | 20+4 pin ATX |
Peripheral (Molex) power cable length | 500 |
Floppy drive power connector | 1 |
CPU power connector (4+4 pin) | Yes |
Floppy disk drive connector | Yes |
Motherboard power cable length | 50 cm |
Peripheral (Molex) power connectors (4-pin) | 2 |
PCI Express power connectors (6+2 pin) | 2 |
Cabling Type | Non-Modular |
