Cooling type | Active |
Fan Diameter | 12 cm |
Number of fans | 1 fan(s) |
On/off switch | Yes |
Product colour | Black |
Combined power (+12V) | 648 W |
Power protection features | Short circuit |
Input current | 5 A |
Max output current (+3.3V) | 19 A |
Combined power (+3.3V) | 120 W |
AC input frequency | 50 - 60 Hz |
AC input voltage | 220 - 240 V |
Combined power (-12V) | 3.6 W |
Combined power (+5V) | 120 W |
Total power | 650 W |
Max output current (+5V) | 19 A |
Hold time | 14 ms |
Max output current (+12V) | 54 A |
Combined power (+5Vsb) | 15 W |
Power Factor Correction (PFC) type | Active |
Efficiency | 88% |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
Power Good signal delay range | 100 - 500 ms |
Depth | 140 mm |
Height | 86 mm |
Width | 150 mm |
Weight | 1.27 kg |
Certification | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
Bearing technology | HDB |
Power supply unit (PSU) form factor | ATX |
80 PLUS Certification | 80 PLUS Bronze |
Mean time between failures (MTBF) | 100000 h |
Purpose | PC |
ATX version | 2.52 |
PACKAGE WEIGHT | 1.67 kg |
Package width | 190 mm |
Package depth | 245 mm |
Package height | 110 mm |
Cabling Type | Non-Modular |
PCI Express power connectors (6+2 pin) | 4 |
Peripheral (Molex) power connectors (4-pin) | 3 |
EPS power connector (8-pin) | Yes |
ATX Power connector (24-pin) | Yes |
Number of SATA power connectors | 6 |
Motherboard power connector | 24-pin ATX |
EPS power connector (4+4 pin) | Yes |
Noise level (quiet mode, 50%) | 26.5 dB |
Noise level (full-load mode, 100%) | 42.5 dB |
Harmonized System (HS) code | 84733020 |
