Product colour | Black |
Number of fans | 1 fan(s) |
Fan Diameter | 12 cm |
On/off switch | Yes |
Power protection features | Short circuit |
Combined power (+5V) | 120 W |
Max output current (+3.3V) | 20 A |
Hold time | 16 ms |
Total power | 750 W |
Combined power (+3.3V) | 120 W |
Combined power (-12V) | 3.6 W |
Combined power (+12V) | 750 W |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Combined power (+5Vsb) | 12.5 W |
Max output current (+12V) | 62.5 A |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Max output current (+5Vsb) | 2.5 A |
Efficiency | 85% |
Operating temperature (T-T) | 0 - 40 °C |
Depth | 140 mm |
Width | 150 mm |
Height | 86 mm |
ATX version | 2.4 |
Purpose | PC |
80 PLUS Certification | 80 PLUS Bronze |
Mean time between failures (MTBF) | 100000 h |
Bearing technology | HDB |
Package Type | Box |
CABLES INCLUDED | AC |
Cabling Type | Non-Modular |
ATX power connector (20+4 pin) | Yes |
Motherboard power cable length | 50 cm |
SATA power cable length | 700 mm |
EPS power connector (4+4 pin) | Yes |
PCI Express power cable length | 62 cm |
Peripheral (Molex) power cable length | 500 |
Peripheral (Molex) power connectors (4-pin) | 1 |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 2 |
PCI Express power connectors (6+2 pin) | 2 |
