Number of fans | 1 fan(s) |
Fan location | Top |
Product colour | Black |
On/off switch | Yes |
Fan Diameter | 12 cm |
Cooling type | Active |
Power protection features | Over power |
Efficiency | 90% |
AC input frequency | 50/60 Hz |
Total power | 1000 W |
AC input voltage | 100 - 240 V |
Combined power (+3.3V) | 120 W |
Combined power (+12V) | 999.6 W |
Combined power (+5V) | 120 W |
Max output current (-12V) | 0.3 A |
Max output current (+5V) | 22 A |
Max output current (+5Vsb) | 3 A |
Max output current (+12V) | 83.3 A |
Power Good signal delay range | 100 - 150 ms |
Hold time | 16 ms |
Combined power (-12V) | 3.6 W |
Max output current (+3.3V) | 22 A |
Power Factor Correction (PFC) type | Active |
Operating temperature (T-T) | 0 - 40 °C |
Height | 85 mm |
Depth | 150 mm |
Width | 150 mm |
Mean time between failures (MTBF) | 100000 h |
80 PLUS Certification | 80 PLUS Gold |
Bearing technology | FDB |
Power supply unit (PSU) form factor | ATX |
ATX version | 3.1 |
Purpose | PC |
Package Type | Box |
Certification | CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH |
Compliance certificates | RoHS |
Cabling Type | Modular |
Motherboard power cable length | 54 cm |
Motherboard power connector | 24-pin ATX |
