On/off switch | Yes |
Product colour | Black |
Fan speed | 0 - 1400 RPM |
Fan location | Top |
Number of fans | 1 fan(s) |
Fan Diameter | 12 cm |
Cooling type | Active |
Power protection features | Short circuit |
AC input voltage | 230 V |
Max output current (+5Vsb) | 3 A |
Total power | 500 W |
Max output current (+12V) | 70 A |
Max output current (-12V) | 0.3 A |
Max output current (+3.3V) | 20 A |
Operating temperature (T-T) | 0 - 105 °C |
Height | 87 mm |
Weight | 2.06 kg |
Depth | 140 mm |
Width | 150 mm |
Supported motherboard form factors | ATX, micro BTX, Mini-ATX |
Bearing technology | FDB |
Mean time between failures (MTBF) | 80000 h |
Power supply unit (PSU) form factor | ATX |
Purpose | PC |
80 PLUS Certification | 80 PLUS Bronze |
Package Type | Box |
CABLES INCLUDED | AC, CPU, PCIe, Peripheral (Molex), SATA |
SATA power cable length | 820 mm |
Motherboard power connector | 24-pin ATX |
Number of SATA power connectors | 5 |
PCI Express power connectors (6+2 pin) | 1 |
Peripheral (Molex) power connectors (4-pin) | 1 |
PCI Express power cable length | 56 cm |
Cabling Type | Non-Modular |
Motherboard power cable length | 57 cm |
Peripheral (Molex) power cable length | 820 mm |
EPS power connector (4+4 pin) | Yes |
