Number of fans | 1 fan(s) |
Product colour | Black |
Fan Diameter | 14 cm |
Input current | 10 A |
Total power | 750 W |
Combined power (+5V) | 120 W |
AC input frequency | 50 - 60 Hz |
Max output current (-12V) | 0.3 A |
Max output current (+12V) | 62.5 A |
AC input voltage | 100 - 240 V |
Max output current (+3.3V) | 22 A |
Max output current (+5Vsb) | 3 A |
Max output current (+5V) | 22 A |
Operating temperature (T-T) | 40 - 50 °C |
Depth | 150 mm |
Height | 86 mm |
Width | 150 mm |
Weight | 2.31 kg |
Certification | CE, FCC, KCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE |
Purpose | PC |
80 PLUS Certification | 80 PLUS Gold |
Mean time between failures (MTBF) | 100000 h |
EPS version | 2.92 |
ATX version | 2.52 |
Power supply unit (PSU) form factor | ATX |
Package width | 210 mm |
PACKAGE WEIGHT | 2.69 kg |
Package depth | 300 mm |
Package height | 110 mm |
Peripheral (Molex) power connectors (4-pin) | 3 |
EPS power connector (4+4 pin) | Yes |
Number of SATA power connectors | 8 |
EPS power connector (8-pin) | Yes |
SATA power cable length | 500 |
PCI Express power connectors (6+2 pin) | 4 |
Motherboard power cable length | 50 cm |
Motherboard power connector | 24-pin ATX |
Peripheral (Molex) power cable length | 150 mm |
ATX Power connector (24-pin) | Yes |
Harmonized System (HS) code | 84733020 |
