Cooling type | Active |
Product colour | Black |
Fan location | Top |
Fan Diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Input current | 8 - 4 A |
Hold time | 16 ms |
AC input voltage | 100 - 240 V |
Max output current (+5V) | 15 A |
Max output current (+5Vsb) | 3 A |
Combined power (-12V) | 3.6 W |
Combined power (+3.3V) | 108 W |
Max output current (+12V) | 43.5 A |
Combined power (+5Vsb) | 15 W |
Power factor | 0.9 |
Efficiency | 85% |
Power Factor Correction (PFC) type | Active |
Combined power (+12V) | 522 W |
AC input frequency | 50 - 60 Hz |
Total power | 550 W |
Max output current (-12V) | 0.3 A |
Power protection features | Over power |
Combined power (+5V) | 108 W |
Max output current (+3.3V) | 18 A |
Height | 86 mm |
Depth | 140 mm |
Width | 150 mm |
Power supply unit (PSU) form factor | ATX |
80 PLUS Certification | 80 PLUS Bronze |
Mean time between failures (MTBF) | 100000 h |
Purpose | PC |
Bearing technology | HDB |
ATX version | 2.31 |
ATX power connector (20+4 pin) | Yes |
Motherboard power cable length | 55 cm |
Peripheral (Molex) power cable length | 500 |
Peripheral (Molex) power connectors (4-pin) | 3 |
PCI Express power connectors (6+2 pin) | 2 |
Number of SATA power connectors | 6 |
SATA power cable length | 500 |
CPU power connector (4+4 pin) | Yes |
PCI Express power cable length | 55 cm |
Floppy drive power connector | 1 |
Motherboard power connector | 20+4 pin ATX |
CPU power cable length | 60 cm |
Cabling Type | Non-Modular |
Floppy disk drive connector | Yes |
PCI Express connector | Yes |
Harmonized System (HS) code | 84733020 |
