Product colour | White |
Number of fans | 1 fan(s) |
Fan location | Top |
On/off switch | Yes |
Fan Diameter | 12 cm |
Cooling type | Active |
Combined power (-12V) | 3.6 W |
Total power | 650 W |
Power Factor Correction (PFC) type | Active |
AC input frequency | 50/60 Hz |
Power protection features | Overcharge |
Combined power (+5Vsb) | 15 W |
Power Good signal delay range | 100 - 150 ms |
Power factor | 0.9 |
Max output current (+5Vsb) | 3 A |
Max output current (+12V) | 54.1 A |
Max output current (+5V) | 20 A |
AC input voltage | 155-240 V |
Combined power (+12V) | 649.2 W |
Input current | 6.3 A |
Combined power (+3.3V) | 100 W |
Max output current (-12V) | 0.3 A |
Max output current (+3.3V) | 20 A |
Combined power (+5V) | 100 W |
Weight | 2.23 kg |
Height | 86 mm |
Depth | 150 mm |
Width | 140 mm |
80 PLUS Certification | 80 PLUS Silver |
ATX version | 3.0 |
Purpose | PC |
Mean time between failures (MTBF) | 100000 h |
Power supply unit (PSU) form factor | ATX |
Bearing technology | FDB |
Package depth | 206 mm |
Package height | 117 mm |
Package Type | Box |
Package width | 254 mm |
PACKAGE WEIGHT | 2.6 kg |
Motherboard power connector | 20+4 pin ATX |
CPU P4 connector (4-pin) | 1 |
CPU power cable length | 60 cm |
PCI Express power connectors (6+2 pin) | 2 |
Peripheral (Molex) power cable length | 500 mm |
ATX power connector (20+4 pin) | Yes |
Peripheral (Molex) power connectors (4-pin) | 2 |
SATA power cable length | 120 mm |
Motherboard power cable length | 60 cm |
Floppy disk drive connector | Yes |
Number of SATA power connectors | 5 |
Cabling Type | Non-Modular |
CPU power connector (4+4 pin) | Yes |
PCI Express power cable length | 65 cm |
Warranty period | 3 year(s) |
