On/off switch | Yes |
Fan location | Top |
Number of fans | 1 fan(s) |
Product colour | Black |
Cooling type | Active |
Fan Diameter | 12 cm |
Max output current (+5V) | 15 A |
Maximum input current (@110V) | +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V |
Combined power (+5Vsb) | 15 W |
Power Factor Correction (PFC) type | Active |
Max output current (-12V) | 0.3 A |
Max output current (+12V1) | 22 A |
Max output current (+5Vsb) | 3 A |
AC input voltage | 115 - 230 V |
Max output current (+3.3V) | 18 A |
AC input frequency | 47 - 63 Hz |
Max output current (+12V2) | 22 A |
Combined power (+5V) | 120 W |
Combined power (-12V) | 3.6 W |
Combined power (+3.3V) | 120 W |
Total power | 520 W |
Weight | 1.25 kg |
Height | 86 mm |
Depth | 140 mm |
Width | 150 mm |
Noise level | 21 dB |
ATX version | 2.31 |
Power supply unit (PSU) form factor | ATX |
Purpose | PC |
Package depth | 95 mm |
PACKAGE WEIGHT | 1.59 kg |
Package width | 240 mm |
Package Type | Box |
Package height | 170 mm |
ATX power connector (20+4 pin) | Yes |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 4 |
Floppy disk drive connector | Yes |
PCI Express connector | Yes |
Peripheral (Molex) power connectors (4-pin) | 4 |
Floppy drive power connector | 1 |
CPU power connector (4+4 pin) | Yes |
PCI Express power connectors (6+2 pin) | 1 |
Cabling Type | Non-Modular |
Harmonized System (HS) code | 84733020 |
