Fan location | Top |
Fan Diameter | 14 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Cooling type | Active |
Product colour | Black |
Total power | 1050 W |
Efficiency | 92% |
Combined power (+12V) | 1050 W |
Combined power (+3.3V) | 130 W |
Power Factor Correction (PFC) type | Active |
Max output current (+5Vsb) | 3 A |
Combined power (+5Vsb) | 15 W |
Max output current (+12V) | 87.5 A |
AC input voltage | 100 - 240 V |
Input current | 15 A |
Max output current (+5V) | 25 A |
AC input frequency | 50/60 Hz |
Power protection features | Short circuit |
Max output current (+3.3V) | 25 A |
Combined power (-12V) | 3.6 W |
Max output current (+12V1) | 0.3 A |
Combined power (+5V) | 130 W |
Depth | 180 mm |
Height | 86 mm |
Width | 150 mm |
80 PLUS Certification | 80 PLUS Platinum |
EPS version | 2.92 |
Purpose | PC |
ATX version | 2.4 |
Supported motherboard form factors | ATX |
Power supply unit (PSU) form factor | ATX |
Silent mode | Yes |
Cabling Type | Fully-Modular |
ATX power connector (20+4 pin) | Yes |
Peripheral (Molex) power connectors (4-pin) | 8 |
Number of SATA power connectors | 8 |
Motherboard power connector | 20+4 pin ATX |
PCI Express power connectors (6+2 pin) | 6 |
CPU power connector (4+4 pin) | Yes |
Hazard pictogram(s) | GHS09: Environmental hazard |
