Number of fans | 1 fan(s) |
Illumination | No |
Fan Diameter | 12 cm |
On/off switch | Yes |
Cooling type | Active |
Product colour | Black |
Total power | 750 W |
AC input voltage | 100 - 240 V |
Combined power (+12V) | 744 W |
Efficiency | 90% |
AC input frequency | 47 - 63 Hz |
Power protection features | Over power |
Combined power (+5V) | 110 W |
Combined power (+3.3V) | 110 W |
Maximum input current (@110V) | 8 A |
Power Factor Correction (PFC) type | Active |
Max output current (-12V) | 0.3 A |
Combined power (+5Vsb) | 12.5 W |
Maximum input current (@220V) | 4 A |
Max output current (+5V) | 20 A |
Max output current (+12V) | 62 A |
Max output current (+3.3V) | 20 A |
Max output current (+5Vsb) | 2.5 A |
Combined power (-12V) | 3.6 W |
Depth | 140 mm |
Width | 150 mm |
Height | 86 mm |
Purpose | PC |
80 PLUS Certification | 80 PLUS Gold |
Power supply unit (PSU) form factor | ATX |
Package Type | Box |
Cabling Type | Fully-Modular |
PCI Express power connectors (6+2 pin) | 3 |
ATX Power connector (24-pin) | No |
Peripheral (Molex) power connectors (4-pin) | 4 |
Motherboard power cable length | 45 cm |
EPS power connector (8-pin) | No |
Motherboard power connector | 20+4 pin ATX |
ATX power connector (20+4 pin) | No |
EPS power connector (4+4 pin) | Yes |
Number of SATA power connectors | 8 |
CPU power connector (4+4 pin) | Yes |
Harmonized System (HS) code | 84733020 |
