Number of fans | 1 fan(s) |
Fan Diameter | 13.5 cm |
Product colour | Black |
Cooling type | Active |
Illumination | No |
Max output current (-12V) | 0.3 A |
Max output current (+12V) | 83.5 A |
Efficiency | 90% |
Power Factor Correction (PFC) type | Active |
AC input frequency | 50 - 60 Hz |
Combined power (+3.3V) | 120 W |
Max output current (+5V) | 22 A |
Power protection features | Over power |
Combined power (-12V) | 3.6 W |
AC input voltage | 100 - 240 V |
Max output current (+5Vsb) | 3 A |
Combined power (+12V) | 1000 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 22 A |
Combined power (+5V) | 120 W |
Total power | 1000 W |
Depth | 150 mm |
Height | 86 mm |
Width | 150 mm |
ATX version | 3.0 |
Bearing technology | FDB |
Power supply unit (PSU) form factor | ATX |
80 PLUS Certification | 80 PLUS Gold |
Purpose | PC/Server |
Motherboard power connector | 20+4 pin ATX |
PCI Express power cable length | 75 cm |
Peripheral (Molex) power cable length | 850 mm |
SATA power cable length | 850 |
Floppy disk drive connector | Yes |
EPS power connector (8-pin) | No |
Peripheral (Molex) power connectors (4-pin) | 4 |
Motherboard power cable length | 60 cm |
Number of SATA power connectors | 12 |
PCI Express power connectors (6+2 pin) | 6 |
Cabling Type | Fully-Modular |
EPS power connector (4+4 pin) | Yes |
PCI Express power connectors (16-pin) | 1 |
EPS cable length | 70 cm |
