Fan Diameter | 12 cm |
Cooling type | Active |
Product colour | Black |
Fan location | Top |
Number of fans | 1 fan(s) |
On/off switch | Yes |
Power Good signal delay range | 100 - 150 ms |
Power protection features | Overheating |
AC input frequency | 50/60 Hz |
Combined power (-12V) | 3.6 W |
Max output current (+5V) | 20 A |
Combined power (+3.3V) | 110 W |
Max output current (+12V) | 45,5 A |
AC input voltage | 100 - 240 V |
Hold time | 16 ms |
Max output current (+5Vsb) | 2.5 A |
Power Factor Correction (PFC) type | Active |
Combined power (+12V) | 546 W |
Efficiency | 85% |
Total power | 550 W |
Max output current (-12V) | 0.3 A |
Combined power (+5V) | 110 W |
Max output current (+3.3V) | 20 A |
Operating temperature (T-T) | 0 - 40 °C |
Width | 150 mm |
Height | 86 mm |
Depth | 140 mm |
Purpose | PC |
Power supply unit (PSU) form factor | ATX |
Bearing technology | HDB |
ATX version | 2.4 |
80 PLUS Certification | 80 PLUS Bronze |
Mean time between failures (MTBF) | 100000 h |
Package Type | Box |
Certification | CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH |
Compliance certificates | WEEE |
Motherboard power cable length | 50 cm |
Cabling Type | Non-Modular |
Motherboard power connector | 24-pin ATX |
