Fan Diameter | 12 cm |
Product colour | Black |
Input current | 10 A |
Max output current (+5Vsb) | 2.5 A |
Combined power (-12V) | 3.6 W |
Max output current (-12V) | 0.3 A |
Power Factor Correction (PFC) type | Active |
Combined power (+5V) | 100 W |
AC input voltage | 100 - 240 V |
Max output current (+5V) | 15 A |
Combined power (+3.3V) | 100 W |
Max output current (+12V) | 62 A |
Combined power (+5Vsb) | 12.5 W |
Combined power (+12V) | 744 W |
Max output current (+3.3V) | 15 A |
Total power | 750 W |
Operating temperature (T-T) | 0 - 50 °C |
Width | 150 mm |
Height | 86 mm |
Depth | 140 mm |
Mean time between failures (MTBF) | 100000 h |
80 PLUS Certification | 80 PLUS Gold |
Power supply unit (PSU) form factor | ATX |
Bearing technology | Sleeve |
Silent mode | Yes |
Supported motherboard form factors | ATX |
Purpose | PC |
Cabling Type | Non-Modular |
PCI Express power connectors (6-pin) | 2 |
Peripheral (Molex) power connectors (4-pin) | 3 |
PCI Express power cable length | 70 cm |
PCI Express connector | Yes |
PCI Express power connectors (8-pin) | 2 |
Motherboard power connector | 20+4 pin ATX |
SATA power cable length | 690 |
Number of SATA power connectors | 6 |
Peripheral (Molex) power cable length | 690 mm |
Harmonized System (HS) code | 84733020 |
Warnings | Do not open the case - risk of electric shock. |
Safety | cTUVus, TUV, CB, CCC, BSMI, CE, FCC |
