Sustainability certificates | ENERGY STAR |
Compliance certificates | WEEE |
Product colour | Black |
Fan Diameter | 13.5 cm |
Number of fans | 1 fan(s) |
Cooling type | Active |
Max output current (+5V) | 20 A |
Combined power (+5Vsb) | 15 W |
AC input voltage | 100 - 240 V |
Power protection features | Over power |
Input current | 11 - 5.5 A |
Max output current (-12V) | 0.3 A |
Combined power (+12V) | 840 W |
Total power | 850 W |
AC input frequency | 50 - 60 Hz |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 70 A |
Combined power (+5V) | 125 W |
Combined power (+3.3V) | 125 W |
Max output current (+5Vsb) | 3 A |
Combined power (-12V) | 3.6 W |
Operating temperature (T-T) | 0 - 50 °C |
Height | 86 mm |
Depth | 160 mm |
Width | 150 mm |
80 PLUS Certification | 80 PLUS Platinum |
Mean time between failures (MTBF) | 150000 h |
ATX version | 3.0 |
Purpose | PC |
Bearing technology | FDB |
Power supply unit (PSU) form factor | ATX |
Package Type | Box |
CABLES INCLUDED | CPU, PCIe, Peripheral (Molex), SATA |
Cabling Type | Fully-Modular |
Motherboard power connector | 24-pin ATX |
SATA power cable length | 860 mm |
EPS power connector (8-pin) | Yes |
Motherboard power cable length | 61 cm |
PCI Express power cable length | 75 cm |
Peripheral (Molex) power cable length | 470 |
ATX power connector (20+4 pin) | Yes |
Peripheral (Molex) power connectors (4-pin) | 3 |
CPU power cable length | 65 cm |
PCI Express power connectors (16-pin) | 1 |
