energy | |
overall performance | 450 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Maximum input current (at 110V) | 6 A |
Maximum input current (at 220V) | 2,5 A |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 85 W |
Combined power (+12V) | 450 W |
Combined current (+5V) | 85 W |
Combined current (-12V) | 3,6 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 16 A |
Max. output current (+12V) | 37,5 A |
Max output current (+5V) | 16 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 2,5 A |
efficiency | 85% |
energy conservation properties | Überstrom, Überlastung, Überspannung, Überhitzung, Kurzschluß |
connections and interfaces | |
Motherboard connector plug | 24-pin ATX |
Number of SATA power plugs | 3 |
Number of Molex connectors 4pin | 3 |
Number of PCI Express power connectors 6+2pin | 2 |
Eigenschaft | Ein-/Ausschalter |
Floppy drive power connection | 1 |
cable type | Nicht-modular |
Services | |
80 plus certification | 80 PLUS Bronze |
purpose | PC |
Power supply unit (PSU) form factor | SFX |
noise level | 43 dB |
storage type | Gewehr |
Mean Time Between Failures (MTBF) | 100000 h |
Design | |
Product color | Schwarz |
cooling | Aktiv |
fan diameter | 8 cm |
number of fans | 1 Lüfter |
fan placement | Oben |
weight and dimensions | |
broad | 100 mm |
depth | 125 mm |
height | 63 mm |
Weight | 1,22 kg |
logistic data | |
Goods tariff number (HS) | 84733020 |
