Fan location | Top |
Product colour | White |
Cooling type | Active |
On/off switch | Yes |
Fan Diameter | 12 cm |
Max output current (-12V) | 0.3 A |
Total power | 750 W |
Combined power (+12V) | 744 W |
Combined power (+5V) | 110 W |
Max output current (+3.3V) | 20 A |
Max output current (+5V) | 20 A |
AC input voltage | 90 - 264 V |
Max output current (+12V) | 62 A |
AC input frequency | 47 - 63 Hz |
Efficiency | 89% |
Combined power (+3.3V) | 110 W |
Operating temperature (T-T) | 0 - 50 °C |
Width | 140 mm |
Weight | 2.08 kg |
Depth | 150 mm |
Height | 86 mm |
Purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX version | 3.0 |
Mean time between failures (MTBF) | 100000 h |
80 PLUS Certification | 80 PLUS Gold |
Bearing technology | FDB |
Package Type | Box |
SATA power cable length | 750 |
Motherboard power cable length | 60 cm |
PCI Express power connectors (6+2 pin) | 2 |
Motherboard power connector | 24-pin ATX |
Cabling Type | Fully-Modular |
Number of SATA power connectors | 8 |
CPU P4 connector (4-pin) | 1 |
CPU power cable length | 75 cm |
CPU power connector (4+4 pin) | Yes |
PCI Express power connectors (12+4 pin) | 1 |
PCI Express power connectors (12+4 pin) cable length | 650 mm |
