Product colour | Black |
AC input frequency | 47 - 63 Hz |
Power factor | 0.9 |
Power protection features | Over power |
Max output current (-12V) | 0.3 A |
Power Factor Correction (PFC) type | Active |
Efficiency | 90% |
Combined power (+3.3V) | 90 W |
Combined power (+5V) | 90 W |
Total power | 350 W |
AC input voltage | 90 - 264 V |
Max output current (+12V1) | 29.17 A |
Max output current (+5Vsb) | 2.5 A |
Max output current (+3.3V) | 17 A |
Combined power (+12V) | 350 W |
Operating temperature (T-T) | 0 - 40 °C |
Depth | 150 mm |
Height | 40.5 mm |
Weight | 960 g |
Width | 81.5 mm |
Mean time between failures (MTBF) | 100000 h |
80 PLUS Certification | 80 PLUS Gold |
ATX version | 2.4 |
Power supply unit (PSU) form factor | Flex ATX |
Noise level | 20 dB |
Purpose | PC/Server |
Floppy drive power connector | 1 |
PCI Express power cable length | 35 cm |
Motherboard power connector | 20+4 pin ATX |
Motherboard power cable length | 35 cm |
Peripheral (Molex) power cable length | 150 |
ATX power connector (20+4 pin) | Yes |
EPS power connector (8-pin) | Yes |
Floppy disk drive connector | Yes |
Floppy disk drive cable length | 35 cm |
Cabling Type | Non-Modular |
PCI Express connector | Yes |
PCI Express power connectors (6-pin) | 1 |
Number of SATA power connectors | 3 |
Peripheral (Molex) power connectors (4-pin) | 2 |
SATA power cable length | 350 mm |
Harmonized System (HS) code | 84733020 |
