energy | |
overall performance | 350 W |
AC input voltage | 110 - 240 V |
AC input frequency | 50 - 60 Hz |
input current | 4 - 8 A |
Power Factor Correction Filter (PFC) | Aktiv |
Combined Current (+3.3V) | 26,4 W |
Combined power (+12V) | 156 W |
Combined current (+5V) | 40 W |
Combined current (-12V) | 3,6 W |
Combined current (+5Vsb) | 12,5 W |
Max. output current (+3.3V) | 8 A |
Max. output current (+12V1) | 13 A |
Max output current (+12V2) | 13 A |
Max output current (+5V) | 8 A |
Max. output current (-12V) | 0,3 A |
Max. output current (+5Vsb) | 2,5 A |
energy conservation properties | Überstrom, Überspannung, Kurzschluß |
connections and interfaces | |
Motherboard connector plug | 20+4 pin ATX |
Number of SATA power plugs | 3 |
Number of Molex connectors 4pin | 2 |
Number of PCI Express power connectors 6+2pin | 1 |
Eigenschaft | CPU Stecker (4+4 pin) |
Floppy drive power connection | 1 |
Services | |
80 plus certification | 80 PLUS |
purpose | PC |
Power supply unit (PSU) form factor | ATX |
Design | |
Product color | Grau |
fan diameter | 8 cm |
number of fans | 1 Lüfter |
weight and dimensions | |
broad | 85 mm |
depth | 175 mm |
height | 65 mm |
Weight | 990 g |
logistic data | |
Goods tariff number (HS) | 84733020 |
