Fan speed | 1800 |
Product colour | Black |
Fan location | Top |
Fan Diameter | 12 cm |
Number of fans | 1 fan(s) |
Max output current (+3.3V) | 20 A |
Combined power (+5V) | 100 W |
Power Factor Correction (PFC) type | Active |
Hold time | 16 ms |
Combined power (+3.3V) | 100 W |
Max output current (+12V) | 33 A |
Combined power (-12V) | 6 W |
Max output current (+5Vsb) | 2.5 A |
Max output current (-12V) | 0.5 A |
Combined power (+5Vsb) | 12.5 W |
AC input voltage | 230 V |
Max output current (+5V) | 14 A |
AC input frequency | 50 - 60 Hz |
Combined power (+12V) | 396 W |
Input current | 5 A |
Total power | 450 W |
Operating temperature (T-T) | 5 - 35 °C |
Storage temperature (T-T) | -40 - 55 °C |
Storage relative humidity (H-H) | 10 - 95% |
Operating relative humidity (H-H) | 20 - 80% |
Height | 86 mm |
Width | 150 mm |
Depth | 140 mm |
Certification | CE, TUV SUD, CB, EAC, RCM |
Purpose | PC |
Power supply unit (PSU) form factor | ATX |
ATX version | 2.3 |
Mean time between failures (MTBF) | 100000 h |
Cabling Type | Non-Modular |
Floppy disk drive connector | Yes |
Motherboard power connector | 24-pin ATX |
ATX Power connector (24-pin) | Yes |
PCI Express power connectors (6+2 pin) | 2 |
Peripheral (Molex) power connectors (4-pin) | 4 |
Peripheral (Molex) power cable length | 450 mm |
Floppy disk drive cable length | 15 cm |
PCI Express power cable length | 45 cm |
CPU power connector (4+4 pin) | Yes |
