Device Location | Plug-in Card |
Form factor | M.2 22x80mm |
Storage capacity | 1 TB |
Supports Data Channel | PCIe NVMe 4.0 x4 |
SSD Controller | Phison E18 |
MEMORY TECHNOLOGY | 3D NAND |
Flash Memory Cell Technology | Triple-Level Cell |
External Color | Black |
Maximum Random Read Rate | 900000 IOPS |
Maximum Random Write Rate | 1000000 IOPS |
Maximum Sequential Read Rate | 7000 MB/s |
Maximum Sequential Write Rate | 6000 MB/s |
Total Bytes Written (TBW) | 800 TB |
Mean Time Between Failures | 1800000 hr |
Solid State Drive Features | NVMe Support |
Vibration Tolerance Operating | 2.17G @ 7-800Hz |
Vibration Tolerance Storage | 20G @ 20-1000Hz |
Maximum Power Consumption | 6.3 W |
Minimum Power Consumption | 5 mW |
Maximum Operating Ambient Temperature | 70 °C |
Minimum Operating Ambient Temperature | 0 °C |
Maximum Non-Operating Ambient Temperature | 85 °C |
Minimum Non-Operating Ambient Temperature | -40 °C |
Width (mm) | 80 mm |
Height (mm) | 22 mm |
Depth (mm) | 2.21 mm |
Nominal Weight | 7 g |
Warranty Term (month) | 60 month(s) |
Warranty Validation Criteria | Serial Number |
Box Weight Brutto (kg) | 0.39 kg |
Package Type | Retail |
EAN Code | 740617324433 |
