Write latency | 30 µs |
TBW rating | 3504 |
Target workload | Mixed Use (MU) |
Random write (4KB) | 78000 IOPS |
H/W PLP function | Yes |
Memory type | 3D TLC NAND |
Hot-Plug support | Yes |
Use conditions | Server/Enterprise |
Random read (4KB) | 94000 IOPS |
Hardware Encryption | No |
SSD Capacity | 1.92 TB |
Data Transfer Rate | 6 Gbit/s |
Write Speed | 530 MB/s |
Read speed | 560 MB/s |
Mean time between failures (MTBF) | 2000000 h |
Read latency | 200 µs |
SSD form factor | 2.5" |
Interface | Serial ATA III |
Component for | Server/workstation |
Power consumption (read) | 1.6 W |
Power consumption (idle) | 1.3 W |
Power consumption (write) | 3.6 W |
Power consumption (average) | 1.45 W |
Non-operating vibration | 20 G |
Storage temperature (T-T) | -40 - 85 °C |
Operating temperature (T-T) | 0 - 70 °C |
Operating vibration | 2.17 G |
Weight | 69 g |
Height | 7 mm |
Width | 69.8 mm |
Depth | 100.1 mm |
Package depth | 9.14 mm |
Package width | 129.5 mm |
PACKAGE WEIGHT | 91.2 g |
Package height | 184.2 mm |
Master (outer) case height | 69.8 mm |
Master (outer) case width | 135.9 mm |
Master (outer) case gross weight | 989.98 g |
Master (outer) case length | 203.2 mm |
Products per master (outer) case | 10 pc(s) |
Warnings | Do not open the appliance casing, risk of damage. |
