| processor | |
| GPU family | Intel |
| GPU | Arc B580 |
| processor clock speed | 2740 MHz |
| Maximum resolution | 7680 x 4320 Pixel |
| Parallel processing technology | Nicht unterstützt |
| Maximale Displays pro Videokarte | 4 |
| Radiation Accelerator | 20 |
| Storage | |
| Separate graphics adapter memory | 12 GB |
| Graphics card memory type | GDDR6 |
| Memory interface width | 192 Bit |
| Memory bandwidth (max) | 456 GB/s |
| connections and interfaces | |
| interface | PCI Express x8 4.0 |
| Number of HDMI ports | 1 |
| HDMI-Version | 2.1 |
| Number of DisplayPort connections | 3 |
| DisplayPorts-Version | 2.1 |
| Services | |
| DirectX-Version | 12 Ultimate |
| OpenGL-Version | 4.6 |
| OpenCL-Version | 3.0 |
| Intel® Xe Matrix Extensions (Intel® XMX) Motoren | 160 |
| Xe-Kerne | 20 |
| NPU-Leistung bis zu | 233 TOPs |
| Design | |
| cooling | Aktiv |
| number of fans | 3 Lüfter |
| number of slots | 2,2 |
| Product color | Blau |
| energy | |
| My. System power failure | 600 W |
| Power consumption (standard operation) | 200 W |
| Additional power connections | 1x 8-pin |
| Power supply placement | Oben |
| system requirement | |
| Supports Windows operating systems | Windows 10, Windows 11 |
| Minimum system requirements | PCI-Express compliant MB with one x16 PCIe slot |
| Minimum processor | 10th Gen Intel Core / AMD Ryzen 3000 Series Processors or newer with compatible motherboards supporting Resizable BAR / Smart Access Memory |
| Minimum required RAM | 8000 MB |
| weight and dimensions | |
| Weight | 954 g |
| Length (mm) | 315 mm |
| depth | 44 mm |
| height | 117 mm |
| packaging type | Box |
| Other functions | |
| Eigenschaft | HDMI |
