Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Ray accelerators | 18 |
Graphics processor | Arc B570 |
Maximum Resolution | 7680 x 4320 pixels |
MIRACLES | No |
Graphics processor family | Intel |
Memory bus | 160 bit |
Memory bandwidth (max) | 380 GB/s |
Discrete graphics card memory | 10 GB |
Graphics card memory type | GDDR6 |
Number of slots | 2.2 |
Product colour | White |
Cooling type | Active |
Number of fans | 2 fan(s) |
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 600 W |
Power supply location | Top |
Power consumption (typical) | 150 W |
Power consumption (max) | 170 W |
Depth | 44 mm |
Height | 105 mm |
Length | 242 mm |
Minimum system requirements | PCI-Express compliant MB with one x16 PCIe slot |
Minimum RAM | 8000 MB |
Windows operating systems supported | Windows 11 |
Dual Link DVI | No |
OpenGL version | 4.6 |
Xe-cores | 18 |
Intel® Xe Matrix Extensions (Intel® XMX) Engines | 144 |
OpenCL version | 3.0 |
NPU performance up to | 203 TOPs |
TV tuner integrated | No |
DirectX version | 12 Ultimate |
Package Type | Box |
DisplayPort version | 2.1 |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
Interface Type | PCI Express x8 4.0 |
DisplayPorts quantity | 3 |
