Parallel processing technology support | Not supported |
MIRACLES | No |
Maximum displays per videocard | 4 |
Maximum Resolution | 7680 x 4320 pixels |
Processor frequency | 2740 MHz |
Graphics processor | Arc B580 |
Graphics processor family | Intel |
Ray accelerators | 20 |
Memory bus | 192 bit |
Discrete graphics card memory | 12 GB |
Memory bandwidth (max) | 456 GB/s |
Graphics card memory type | GDDR6 |
Product colour | White |
Number of slots | 2.2 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Minimum system power supply | 600 W |
Supplementary power connectors | 1x 8-pin |
Power supply location | Top |
Power consumption (typical) | 200 W |
Length | 315 mm |
Depth | 44 mm |
Height | 117 mm |
Minimum system requirements | PCI-Express compliant MB with one x16 PCIe slot |
Windows operating systems supported | Windows 11 |
Minimum RAM | 8000 MB |
Dual Link DVI | No |
OpenCL version | 3.0 |
DirectX version | 12 Ultimate |
OpenGL version | 4.6 |
TV tuner integrated | No |
NPU performance up to | 233 TOPs |
Intel® Xe Matrix Extensions (Intel® XMX) Engines | 160 |
Xe-cores | 20 |
Package Type | Box |
DisplayPort version | 2.1 |
DisplayPorts quantity | 3 |
Interface Type | PCI Express x8 4.0 |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
