| Graphics processor | Arc B580 |
| Processor frequency | 2740 MHz |
| Maximum Resolution | 7680 x 4320 pixels |
| MIRACLES | No |
| Parallel processing technology support | Not supported |
| Ray accelerators | 20 |
| Graphics processor family | Intel |
| Maximum displays per videocard | 4 |
| Memory bandwidth (max) | 456 GB/s |
| Graphics card memory type | GDDR6 |
| Discrete graphics card memory | 12 GB |
| Memory bus | 192 bit |
| Cooling type | Active |
| Number of fans | 3 fan(s) |
| Product colour | Blue |
| Number of slots | 2.2 |
| Power consumption (typical) | 200 W |
| Minimum system power supply | 600 W |
| Supplementary power connectors | 1x 8-pin |
| Power supply location | Top |
| Length | 315 mm |
| Weight | 954 g |
| Depth | 44 mm |
| Height | 117 mm |
| Minimum system requirements | PCI-Express compliant MB with one x16 PCIe slot |
| Minimum RAM | 8000 MB |
| Windows operating systems supported | Windows 10 |
| OpenGL version | 4.6 |
| OpenCL version | 3.0 |
| Dual Link DVI | No |
| DirectX version | 12 Ultimate |
| TV tuner integrated | No |
| Intel® Xe Matrix Extensions (Intel® XMX) Engines | 160 |
| Xe-cores | 20 |
| NPU performance up to | 233 TOPs |
| Package Type | Box |
| HDMI version | 2.1 |
| DisplayPorts quantity | 3 |
| Interface Type | PCI Express x8 4.0 |
| DisplayPort version | 2.1 |
| HDMI ports quantity | 1 |
| HDMI | Yes |
