LED indicators | Yes |
Product colour | Blue |
Housing material | Plastic |
Hot keys | Yes |
Power source | DC |
Input voltage | 5 V |
Power consumption (typical) | 0.9 W |
Storage temperature (T-T) | -20 - 60 °C |
Storage relative humidity (H-H) | 0 - 80% |
Operating temperature (T-T) | 0 - 50 °C |
Operating relative humidity (H-H) | 0 - 80% |
Depth | 97.2 mm |
Width | 94.1 mm |
Weight | 580 g |
Height | 26 mm |
Maximum Resolution | 2048 x 1536 pixels |
HD type | QXGA |
Scan interval | 1 |
DDC2B support | Yes |
Package depth | 265 mm |
Package width | 95 mm |
Package height | 220 mm |
PACKAGE WEIGHT | 765 g |
Quick installation guide | Yes |
Manual | Yes |
Built-in Display | No |
Console USB ports quantity | 2 |
Console ports | VGA (D-Sub) |
Keyboard port type | USB |
Audio connections | Yes |
Mouse port type | USB |
Number of computers controlled | 4 |
VGA (D-Sub) ports quantity | 4 |
Video port type | VGA |
USB 2.0 Type-A hub ports quantity | 4 |
Products per master (outer) case | 5 pc(s) |
Master (outer) case width | 232 mm |
Master (outer) case length | 500 mm |
Master (outer) case gross weight | 4.24 kg |
Master (outer) case net weight | 2.9 kg |
Harmonized System (HS) code | 85176200 |
Master (outer) case height | 283 mm |
